MOSAIK DRAIN - Drainage Roller Plates

MODEL
33,60€ m²
33,60€ m²
Taxes included. Shipping costs calculated at checkout.
subtotal
Taxes included. Shipping costs calculated at checkout.
Mosaik Drain Perforated Paving Slabs · Outdoor Paving for Vehicle Traffic
Mosaik Drain Perforated Paving Slab — View 2 · Outdoor Paving for Vehicle Traffic

Description

MOSAIK DRAIN is a drainage mat manufactured in France, designed for driving and parking on unprepared surfaces: grass, dirt, gravel, or damaged surfaces.

Its 20-mm-diameter drainage holes allow water to seep naturally into the ground: the surface remains usable after rain, with no standing water or runoff. It snaps into place without glue or tools, is installed directly on the existing surface, and can be disassembled for reuse. Made from 100% recycled PVC, with a 20-year warranty.

Outdoor Drainage Paving Slabs
Construction Site
Events
Directions and Parking
Simple maintenance

Features

MOSAIK DRAIN Drainage Tread Plate
Dimensions 103.4 x 71.9 cm — usable area 100 x 68 cm, or 0.68 m²
Thickness 27 mm or 40 mm
Weight 16.5 kg per sheet for 27 mm thickness — 25 kg for 40 mm thickness
Material 100% recycled PVC, made in France
Static charge 15 metric tons/m² at 27 mm — 35 metric tons/m² at 40 mm
Reason Diameter 20 mm, height 3 mm
Drainage 20-mm-diameter drainage holes
Installation Clips together without glue or tools, on unprepared surfaces
Maintenance Mop, pressure washer, or floor scrubber
Usage Outdoors — construction sites, events, access, parking
Warranty 20 years
Technical Specifications Traffic ticket at a traffic light

You can also watch the installation video below:

Key strengths

Up to 35 metric tons per square meter

Up to 35 metric tons per square meter

The plate withstands heavy machinery and vehicles while distributing the load across soft ground.

Designed to promote drainage

Designed to promote drainage

The 20-mm holes allow water to seep into the ground: no more puddles or muddy spots after it rains.

Made in France

Made in France

Made of 100% recycled PVC, with a 20-year warranty; fire- and frost-resistant; slip-resistant.

Easy to use

Easy to use

- Glue-free, tool-free installation
- Removable and reusable
- Cut with a jigsaw
- Beveled finishing strips available

Compare with another product

Choose two products to see how they differ.

This product

Choose a product

Solid slabs

Perforated slabs

Tatami Mats / Shock-Absorbing Tiles

Vinyl tiles and planks

Tread plate

Drain

Outdoors—construction sites, events, access, parking

103.4 x 71.9 cm - usable area 100 x 68 cm (0.68 m²)

Thickness: 27 or 40 mm

Starting at €33.60 per square meter

View the product
Compare with

Choose a product

Solid slabs

Perforated slabs

Tatami Mats / Shock-Absorbing Tiles

Vinyl tiles and planks

Interlocking PVC Tile

Factory

Indoors—workshop, garage, warehouse

75 x 75 cm - usable area 0.52 m²

Thickness: 13 mm

Starting at €27.70 per square meter

View the product

Portfolio

  • Outdoor Drainage Paving Slabs — Project 1
  • Outdoor Drainage Paving Slab — Project 2

Customer reviews

★ ★ ★ ★ ★

Johanna Romney

When ordering Tajima vinyl tiles for a 220-square-meter store in Saint Barthélemy (French West Indies), Lionnel was incredibly helpful and professional. He was always available and responded quickly, despite the time difference.
The tiles look flawless. Installation is easy, even for non-professionals.

★ ★ ★ ★ ★

Jean Luc A

Great communication with the team.
Excellent product that’s very easy to install using a mallet and a jigsaw
for cutting.
Tracked shipping
No issues
I highly recommend it
Thank you

★ ★ ★ ★ ★

HD Carshine Holzinger

I ordered some tiles from Germany. I have to say that everything went smoothly, and the package arrived well-packed in about 7 days. The value for money is excellent! The quality is good, too! I’ll be ordering again soon.

FAQ

On what types of floors can these tiles be installed?

On unprepared surfaces—such as grass, dirt, and gravel—as well as on damaged or uneven surfaces. They protect the existing surface.
How does drainage work?

The plate has drainage holes 20 mm in diameter. Rainwater passes through the plate and seeps into the ground instead of pooling on the surface.
How much weight can they hold?

15 metric tons per square meter for a thickness of 27 mm, and up to 35 metric tons per square meter for a thickness of 40 mm.
What is the usable area of a plate?

The panel measures 103.4 x 71.9 cm, with a usable surface area of 100 x 68 cm, or 0.68 m² when assembled.
Does the installation require glue or tools?

No. The panels snap together by hand, without glue or tools. They can be taken apart and reused.
How do you cut a sheet?

With a jigsaw.
Are there any finishing accessories available?

Yes, beveled transition strips are available to connect the surface to the surrounding floor.
